Description
Standard Features
Cabinet Construction
- Stainless steel cabinet construction
- Stainless steel interior and exterior (galvanized steel back & bottom).
- Cyclopentane Insulation – Contains no hydro-fluorocarbons (HFCs) and is environmentally friendly
- Drop-in section:
- Fans force cold air into this enclosed area keeping stored food items consistently cold
- Insulated pan cover with a stainless steel divider which prevents food spillage into the storage area beneath
- Standard 1/6 / 4” food pans are provided. Unit accommodates 6" deep pans
- Side rail cutting board bracket with 9 ½” deep, 1/2” thick cutting board included
- Four (4) 4” diameter swivel casters with front brakes standard.
Refrigeration
- Hydrocarbon refrigerants (R-290) – increases energy efficiency by up to 25% compared to using HFC refrigerants. It is safer for the environment and does not cause ozone depletion.
- Self-contained system, rear mounted compressor.
- Electrodeposition coated evaporator increases performance by maintaining the heat transfer rates over the life of the evaporator and reducing potential corrosion.
- Innovative hot gas frame heating system reduces condensation and increases energy efficiency.
- Refrigerators have a temperature range between 33°F ~ 39°F
Drawer
- Durable drawer gasket with easy replacement.
- Lifetime guaranteed heavy duty all metal handles. (Ni-Cr Plated)
Design
- Self-diagnostic digital temperature control & monitor system
- Digital display allows for easy monitoring
- Digital controls include automatic evaporator fan motor delay.
- Rounded corner design gives a stylish appearance and reduces chances of injury.
Standard
- NSF/ANSI Standard 7 compliant
Connection
- 9 ft long flexible three wire cord with molded plug
Optional Features & Accessories
- 2.5" diameter casters available
- 6" adjustable feet available
- 6” pans available
Warranty
5 Years Parts & Labor
7 Years Compressor
Product Specification
Capacity | 16.7 cu. ft. |
Exterior Dimensions ( L x D x H ) | 60 3/8 x 33 1/32 x 42 1/2 inch |
Net Weight | 315 lb |
Door | 0 |
Shelves | N/A |
Compressor | 1/4 HP |
Refrigerant | R-290 |
Temperature Range | 33℉ ~ 39℉ |
Input (Voltage / Hz / Phase) | 115V / 60Hz / 1Ph |
Amps | 4.7 |
Drawers | 4 |
Pans | 1/6x16 |
Certification Safety | ETL |
Certification Sanitation | ETL |
