Description
True Refrigeration TH-23G~FGD01 Description
This True TH-23G~FGD01 reach-in heated holding cabinet is intended to keep cooked and baked food warm. Keeping temperatures at a set level between 80 and 180 degrees Fahrenheit, this unit has a stainless steel heating element that generates electric heat and low-velocity fans that circulate warm air around the cabinet. Humidity levels can be controlled with a top vent and a water pan is included if extra humidity is needed. For corrosion and dent resistance, this cabinet is made of stainless steel and aluminum, while its walls are foamed with polyurethane insulation to add structure.
The three chrome-plated wire shelves are adjustable on 1⁄2-inch increments to accommodate various products, and this True TH-23G~FGD01 mobile heated cabinet has triple-pane, thermal-insulated door that is transparent to provide product visibility. It has a 12-inch-long aluminum handle that offers a comfortable grip, while the door can close on its own and has a magnetic gasket that prevents warm air from seeping out. Incandescent lighting illuminates the interior and 4-inch-diameter castors help move the unit.
Product Details
- 3 chrome-plated wire shelves can be adjusted in 1⁄2-in. increments
- Incandescent lighting brightens interior
- Triple-pane, thermal-insulated door with 12-in. aluminum handle
- Self-closing door saves energy
- 1-piece magnetic door gasket creates an airtight seal
- Includes a 12-in. L x 20-in. W x 1-in. D water pan for additional humidity
- Requires a dedicated sole use circuit
Cabinet Construction
- Stainless steel exterior front with anodized aluminum ends and a GalFan-coated steel back
- Interior is lined with stainless steel
- Polyurethane foam insulation provides structure
- Welded frame rail is black powder coated to resist corrosion
- 4-in.-diameter castors with locking front set
Heater System
- Holds warm baked and cooked food
- Temperature holding range: 80-180 degrees F
- 1 stainless steel heating element is sheathed to resist corrosion
- Low-velocity fans consistently circulate warm air
- Humidity levels can be adjusted by top vent
- Exterior dial thermometer provides precise temperature readings
Dimensions & Utilities
- Shelves: 217⁄16 in. W x 231⁄4 in. D
- Overall: 27 in. W x 321⁄32 in. D x 843⁄8 in. H
- 7.8 A, 850 W
- 115 V/60 Hz/1 ph, 9-ft. cord with a NEMA 5-15P plug
True Refrigeration TH-23G~FGD01 Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | True Refrigeration |
| Application | Heat Only |
| Construction | Stainless/Aluminum |
| Controls | Dial |
| Depth (in) | 32.03 |
| Door Design | Full |
| Door Type | Glass |
| Heat | Electric |
| Height (in) | 84.38 |
| Hertz | 60 |
| kW | 0.85 |
| Pan Capacity | 3 |
| Sections | 1 |
| Size | Full Height |
| Slide Type | Universal |
| Type | Insulated |
| Voltage | 115 |
| Warranty | 3 years Parts & Labor |
| Width (in) | 27 |
| Series | TH Series |
| Control Location | Top |
| Load Type | Reach In |
| No. of Doors | 1 |
| Phase | 1 |
| Product | Heated Cabinets |
| Product Type | Food Warming Equipment |
| Weight | 290.00 |
